機器配件采用進口加工中心制作
推臺采用進口精密圓柱導軌，精度更高、壽命更長
整機采用噴塑處理，激光切割焊接機身，使用性能更加穩定可靠
Machine accessories are made by imported processing center
The sliding table adopts imported precision cylindrical guide rail, with higher precision and longer service life
The whole machine adopts plastic spraying treatment, laser cutting and welding body, and its performance is more stable and reliable
| 最大鋸切長度 Max.working length | 3200/mm |
| 最大鋸切厚度 Max.working thickness | 78mm |
| 主鋸片尺寸 Main saw size | 305×$30mm |
| 槽鋸片尺寸 Scoring saw size | 100× $20mm |
| 主鋸軸轉速 Main saw spindle speed | 4000/5000r/min |
| 槽鋸軸轉速 Scoring saw spindle speed | 9000r/min |
| 主鋸電機功率 Main saw motor power | 5.5kw |
| 槽鋸電機功率 Scoring saw motor power | 1.1kw |
 |  |
 |  |
